GLASS FIBER MESH FABRICS

Jiuding is the first manufacturer in China to produce glass fiber mesh since, and has grown to be the leading producer for high quality mesh fabrics.

Jiuding Glass Fiber Mesh is made from E or C-glass fiber, coated with high quality synthetic rubber. Coating substance can be SBR(styrene butadiene), acrylic, PVC, etc, which depends on the specific application of mesh. Glass fiber mesh fabrics are an important part of façade systems and internal plastering because they can prevent cracks and reduce the risk of mechanical damage to the surface.

Availability:



Inquire

Performance and characteristics
Product specification
Application field

1. High tensile strength and low elongation for crack prevention

2. Alkali-resistant

3. Produced from E glass for stable fabric quality

4. Nice touch and perfect cutting for ease of application

5.Weight, strength, width, color can be customized

Glass fiber alkali-resistant mesh cloth GLASS FIBER MESH FABRICS

return

Specification	Density Count / 25mm		Treated Woven Mass g / ㎡	Tensile Strength ≥N / 5cm × 20cm		Woven Structure	Remark
Specification	Warp	Weft	Treated Woven Mass g / ㎡	Warp	Weft	Woven Structure	Remark
CAG110-2.5 × 2.5	2.5	2.5	110	1200	1000	Leno	Regular ETAG004
CAG130-2.5 × 2.5	2.5	2.5	130	1200	1400	Leno
CAG145-5 × 5	5	5	145	1200	1400	Leno
CAG75-6 × 6	6	6	75	800	800	Leno
CAG130-6 × 6	6	6	130	1000	1200	Leno
CAG160-6 × 6	6	6	160	2000	2000	Leno
CAG200-6 × 5.5	6	5.5	200	1700	1800	Leno	Heavy mesh for USA market
CAG300-6 × 5.5	6	5.5	300	2800	2800	Leno	Heavy mesh for USA market

Specification	Density Count / 25mm		Treated Woven Mass g / ㎡	Tensile Strength ≥N / 5cm × 20cm		Coating	Remark
	Warp	Weft		Tensile Strength ≥N / 5cm × 20cm
	Warp	Weft		Warp	Weft
CAP60-20 × 10	20	10	65	660	660	SBR	Regular
CAP80-20 × 20	20	20	80	800	800	SBR
CAP75-20 × 10	20	10	75	660	660	Asphalt bitumen
CAGM50-5 × 5	5	5	50	300	300	SBR	Mat combine mesh
CAGT100-6 × 4.5	6	4.5	100	1300	600	SBR	Texturized weft yarn

Specification	Density Count / 25mm		Unit Weight g / ㎡	Tensile Strength ≥N / 5cm × 20cm		Woven Structure	Content Of Resin%
Specification	Warp	Weft	Unit Weight g / ㎡	Warp	Weft	Woven Structure	Content Of Resin%
CAGT100-6 × 4.5	6	4.5	100	1300	600	Leno	16 ± 2
CAG75-6 × 6	6	6	75	800	800	Leno	16 ± 2
CAG55-9 × 7	9	7	55	600	550	Leno	16 ± 2
CAG75-9 × 7	9	7	75	600	800	Leno	16 ± 2

Specification	Density Count / 25mm		Unit Weight g / ㎡	Tensile Strength ≥N / 5cm × 20cm		Woven Structure	Content Of Resin%
Specification	Warp	Weft	Unit Weight g / ㎡	Warp	Weft	Woven Structure	Content Of Resin%
CNT65-9 × 9	9	9	65	550	550	Leno	28 ± 2
CNT80-5 × 5	5	5	80	700	800	Leno	28 ± 2
CNT110-5 × 5	5	5	110	1000	1000	Leno	28 ± 2
CNT145-5 × 5	5	5	145	1400	1600	Leno	28 ± 2
CNT160-5 × 5	5	5	160	1600	1800	Leno	28 ± 2

Specification	Density Count / 25mm		Treated Woven Mass g / ㎡	Tensile Strength ≥N / 5cm × 20cm		Woven Structure	Remark
Specification	Warp	Weft	Treated Woven Mass g / ㎡	Warp	Weft	Woven Structure	Remark
CAG110-2.5 × 2.5	2.5	2.5	110	1200	1000	Leno	Regular ETAG004
CAG130-2.5 × 2.5	2.5	2.5	130	1200	1400	Leno
CAG145-5 × 5	5	5	145	1200	1400	Leno
CAG75-6 × 6	6	6	75	800	800	Leno
CAG130-6 × 6	6	6	130	1000	1200	Leno
CAG160-6 × 6	6	6	160	2000	2000	Leno
CAG200-6 × 5.5	6	5.5	200	1700	1800	Leno	Heavy mesh for USA market
CAG300-6 × 5.5	6	5.5	300	2800	2800	Leno	Heavy mesh for USA market
