9029 yarn

9029 glass fiber roving is specially designed to reinforce epoxy resin. It is suitable for the weaving / weaving and winding process of multi-axial fabrics. It is mainly used in fan blades, high-pressure cylinders and high-pressure pipes.



Inquire

Performance and characteristics
Selection guide
Product specification

1. Good fatigue performance

2. Good corrosion resistance

3. Good textile performance

4. High modulus

9029 yarn

return

Grade	Number (TEX)	Single fiber diameter (μm)	Water content (%)	Flammable content (%)	Tensile strength at break (N / TEX)
HCR9029-300	300 ± 15	14	≤0.10	0.55 ± 0.15	≥0.35
HCR9029-600	600 ± 30	16	≤0.10	0.55 ± 0.15	≥0.35
HCR9029-1200	1200 ± 60	17	≤0.10	0.55 ± 0.15	≥0.35
HCR9029-2400	2400 ± 120	17	≤0.10	0.55 ± 0.15	≥0.35
HM9029-4800	2400 ± 120	24	≤0.10	0.6 ± 0.15	≥0.35

Yarn height (㎜)	Yarn inner diameter (㎜)	Yarn outer diameter (㎜)	Number of pallets
260	160	270 ± 5	3/4
Number of yarn balls per layer	Tray height (㎜)	Tray length (㎜)	Tray width (㎜)
16	940/1200	1120	1120

Grade	Number (TEX)	Single fiber diameter (μm)	Water content (%)	Flammable content (%)	Tensile strength at break (N / TEX)
HCR9029-300	300 ± 15	14	≤0.10	0.55 ± 0.15	≥0.35
HCR9029-600	600 ± 30	16	≤0.10	0.55 ± 0.15	≥0.35
HCR9029-1200	1200 ± 60	17	≤0.10	0.55 ± 0.15	≥0.35
HCR9029-2400	2400 ± 120	17	≤0.10	0.55 ± 0.15	≥0.35
HM9029-4800	2400 ± 120	24	≤0.10	0.6 ± 0.15	≥0.35

Yarn height (㎜)	Yarn inner diameter (㎜)	Yarn outer diameter (㎜)	Number of pallets
260	160	270 ± 5	3/4
Number of yarn balls per layer	Tray height (㎜)	Tray length (㎜)	Tray width (㎜)
16	940/1200	1120	1120
